Design Modules

IntuiCAD combines AutoLisp — long a favorite customization ally — with AutoCad’s powerful dynamic blocks to deliver design tools specifically attuned to exploit the most common, or even SPECIFIC editing capabilities in engineering design.

We make use of solid document creation tools and techniques. We have done extensive research into the specifications of ASCE, AWS, SJI, CRSI, OSHA and others as well as major manufacturers of building components in order to provide you with the most functional tools possible.

Structural Component Manager

SCM is a full service, single sourcing, CAD customization system designed specifically for Structural Engineering.

Mechanical Component Manager

Coming soon.

Electrical Component Manager

Coming soon.

Piping Component Manager

Coming soon.

IntuiCAD SCM is considered a fundamental component to the design drafting profession by the American Design Drafting Association. IntuiCAD SCM and its related material is relevant to the delivery of the design drafting process.

... ADDA feels, it should be considered a key reference tool in furthering the knowledge, abilities, and skills of a properly trained designer or drafter in their pursuit of a professional career and job performance on a daily basis.
